Name: Double Membrane Biogas Holder Balloon Weatherproof For Agricultural Industrial Residential
Brand: Sichuan Mondes Green Technology Co.,Ltd
SKU: MDS-GMG6000
Availability: InStock

Home Products Biogas Holder Balloon

Double Membrane Biogas Holder Balloon Weatherproof For Agricultural Industrial Residential

Product Details:

Place of Origin:	China
Brand Name:	MDS
Certification:	CE, ISO9001:2015
Model Number:	MDS-GMG6000

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	Please contact us
Packaging Details:	Standard export wooden box
Delivery Time:	5~60 days
Payment Terms:	T/T,L/C,Western Union,MoneyGram
Supply Ability:	10 sets per month

Contact Now Chat Now

Detailed Product Description

Application:	Agricultural, Industrial, And Residential Use	Usage:	Gas Storage
Durability:	UV-resistant And Weatherproof	Capacity:	20~20,000m³
Warranty:	10 Years	Safety Features:	Pressure Relief Valve And Leak-proof Design
Color:	White Or Customized	Advantages:	Cost-effective And Eco-friendly
Installation:	Easy To Install And Disassemble	Service Life:	15~25 Years
Highlight:	biogas holder balloon weatherproof , weatherproof biogas balloon , agricultural biogas balloon

Double Membrane Biogas Holder Balloon, Biogas Storage Balloon Weatherproof

Discover the Advantages of the Double Membrane Biogas Balloon for Biogas Storage

Product Overview

The double membrane biogas balloon represents an innovative category of gas storage equipment, distinguished by its numerous unique features and advantages.

Structural Composition

Bottom Membrane: Provides foundational seal with superior corrosion resistance and impermeability, ensuring no gas escapes from the base.
Inner Membrane: Isolates stored gas from pressure-regulating gas, maintaining purity with excellent airtightness and corrosion resistance.
Outer Membrane: Creates pressure-regulating chamber, protects inner membrane, and maintains consistent internal pressure.
Pressure Control Cabinet: Central control system for real-time monitoring and regulation of internal pressure.
Safety Protection Devices: Automatically engage to prevent damage from excessive pressure.
Additional Control Equipment: Includes anti-explosion blower, piping systems, valves, and sensors for optimal performance.

Working Principle

The bottom and outer membranes create a sealed gas storage chamber. The control system automatically adjusts regulating air to maintain optimal pressure as gas volume changes, while the inner membrane prevents mixing of stored gas and regulating air.

Appearance and Fixed Method

Features a 3/4 spherical design, secured to concrete foundations with steel tracks for enhanced stability and seismic resistance.

Main Technical Parameters

S/N	Items	Technical Parameter	Unit	Remarks
1	Capacity	20 ~ 20,000	m³
2	Base Diameter	3.74 ~ 35.00	m
3	Outer Membrane Height	2.77 ~ 26.20	m
4	Operating Pressure	2 ~ 20	mbar
5	Designed Biogas Flow	20 ~ 20,000	m³
6	Motor Power	0.75 ~ 7.5	kw
7	Motor Voltage	380	V	Can be customized
8	Frequency	50	Hz	Can be customized
9	Designed Working Temperature	-30 ~ 70	℃

Advantages

Safety and Reliability: Corrosion-resistant materials with 15-25+ year lifespan, stainless steel connectors, and multiple safety devices.
Environmental Friendliness: No phenol-containing wastewater generation, preventing secondary pollution.
Convenient Installation: Basic concrete foundation required, operational within days.
Cost Efficiency: Full volume utilization, lightweight design reduces foundation costs compared to traditional tanks.

Application

Suitable for storing biogas, air, carbon dioxide, oxygen, coal-bed gas, and natural gas. Widely used in livestock farming, wastewater treatment, food waste processing, landfills, biogas production, and chemical industries.
