Name: Automated Ground Mounted Double Membrane Gas Storage Tank For Cow Farm
Brand: Sichuan Mondes Green Technology Co.,Ltd
SKU: MDS-GMG5000
Availability: InStock

Home Products Double Membrane Gas Storage Tank

Automated Ground Mounted Double Membrane Gas Storage Tank For Cow Farm

Product Details:

Place of Origin:	China
Brand Name:	MDS
Certification:	CE, ISO9001:2015
Model Number:	MDS-GMG5000

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	Please contact us
Packaging Details:	Standard export wooden box
Delivery Time:	5~60 days
Payment Terms:	T/T,L/C,Western Union,MoneyGram
Supply Ability:	20 sets per month

Contact Now Chat Now

Detailed Product Description

Inflation System:	Automatic Inflation System	Size:	Customized
Lifespan:	≥25 Years	Uv Resistance:	≥6
Customization:	Customizable Size And Shape	Durability:	Long Service Life
Installation Duration:	8-15 Days	Installation:	Easy To Install
Material:	High-strength PVC Coated Fabric	Corrosion Resistance:	Resistant To Corrosion
After Warranty Service:	Video Technical Support	Cost-Effective:	Cost-effective Solution For Biogas Storage
Highlight:	ground mounted double membrane gas storage tank , automated membrane gas holder , automated double membrane gas storage tank

Automated Ground-Mounted Double Membrane Biogas Storage Tanks For Cow Farm

Product Overview

These specialized biogas storage tanks, also known as bags or balloons, are designed for diverse gas storage applications while maintaining constant pressure. Constructed from high-strength polyester fiber membranes with double or triple layers, they feature an integrated control system. The inner membrane stores gas while the outer membrane regulates pressure and maintains structural integrity.

Key Advantages

Cost-effective alternative to traditional steel tanks
Extended operational lifespan with durable materials
Enhanced safety features in design
Lightweight construction for easier transportation and installation
Fully automated controls for straightforward operation
Minimal maintenance requirements
Water-free operation prevents freezing complications

Applications

These systems are widely used in agricultural waste-to-energy projects, wastewater treatment plants for methane capture, and industrial gas containment solutions.

Mechanical Calculation and Force Analysis

Structural integrity is ensured through comprehensive analysis of maximum and minimum stresses, considering internal gas pressure fluctuations, environmental loads (wind, snow), and seismic activity. This ensures optimal material selection for specific operational conditions.

Main Technical Parameters

S/N	Item	Parameter Values	Unit
1	Capacity	20~20,000	m³
2	Internal Pressure	≤20	mbar
3	Appearance	Smooth, elastic	---
4	Methane permeability	≤250	cm³/m².24h.0.1MPa
5	Weld seams	≥70	mm
6	Bottom edge	Complete occlusion without leakage	---
7	Embedded parts	10# channel steel, HDG	---
8	Surface resistance	≤109	Ω
9	Inspection window	DN300	---
10	Sealing strip	Special rubber gasket	---
11	Connecting bolt	High-strength bolt, HDG	---

Gas Categories for Storage

Suitable for biogas, coal gas, natural gas, carbon dioxide, and various other biogas and mineral gases.

Additional Benefits

Safety and Reliability: Stable structure without complex components, overpressure safety valve, and biogas leakage alarm system
Environmentally Friendly: No phenolic wastewater production, compliant with environmental standards
Extended Service Life: Inner membrane lasts over 25 years, outer membrane over 20 years
Easy Installation: Requires only basic cement foundation, minimal on-site work
Optimal Storage Capacity: High space utilization without dead zones
Low Maintenance: Simple routine maintenance, resistant to aging and UV exposure
Wide Applicability: Suitable for various neutral gases across multiple industries
Aesthetic Design: 3/4 spherical shape blends well with surroundings
