Large Glass Fused Bolted Steel Tanks Modular Design Durability For Water Management System

Large Glass Fused Bolted Steel Tanks Modular Design Durability For Water Management System

  • Large Glass Fused Bolted Steel Tanks Modular Design Durability For Water Management System
  • Large Glass Fused Bolted Steel Tanks Modular Design Durability For Water Management System
  • Large Glass Fused Bolted Steel Tanks Modular Design Durability For Water Management System
Large Glass Fused Bolted Steel Tanks Modular Design Durability For Water Management System
Product Details:
Place of Origin: China
Brand Name: YITIAN
Certification: NSF/ANSI 61, CE, ISO9001:2015
Model Number: YT-3000DW
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Please contact us
Packaging Details: Angle Iron Frame + Tray + Collision Protection
Delivery Time: 5~60 days
Payment Terms: T/T,L/C,Western Union,MoneyGram
Supply Ability: 20 sets per month
Contact Now Chat Now
Detailed Product Description
Installation Method: Bolted Leakage: Zero
Uv Resistance: High Material: Glass Fused To Steel
Temperature Range: Ambient Maintenance: Low
Customizable: Yes Durability: 30+ Years
Certifications: ISO 9001:2015, NSF/ANSI 61, AWWA D103-09 Application: Water Storage And Treatment
Corrosion Resistance: Excellent Modular Design: Yes
Highlight:

glass fused bolted steel tanks modular

,

modular glass fused steel tanks

,

durability glass fused steel tanks

Large Bolted Steel Water Storage Tanks Modular Design For Water Management System
Product Overview

Large Potable Water Storage Tanks bolted steel water storage tanks constitute a significant and prudent investment for any water management system, whether it serves a small community or a large industrial complex. These tanks are meticulously engineered to provide a consistent and reliable supply of clean, safe drinking water.

Constructed from high-grade steel, these tanks are designed to withstand harsh environmental conditions, including extreme temperatures, heavy rainfall, and strong winds. Their robust construction ensures minimal maintenance over their lifespan, often extending several decades.

The versatility of bolted steel potable water storage tanks allows customization for various applications and environments. Available in multiple sizes and configurations, they can be tailored to optimize space utilization and aesthetic integration.

Large Glass Fused Bolted Steel Tanks Modular Design Durability For Water Management System 0
Main Technical Parameters
Coating Color Dark Blue, Dark Green Or Customized
Coating Thickness 0.25-0.45mm
Acid And Alkalinity Proof Standard PH 3-11, Special PH 1-14
Adhesion 3.450N/cm
Hardness 6.0 (mohs)
Service Life ≥30 Years
Holiday Test 900 ~ 1500v
Permeability Gas Liquid Impermeable
Easy To Clean Smooth, Anti-adhesion, Glossy, Inert
Elasticity Same as steel plate, about 500KN/mm
Corrosion Resistance Excellent, suitable for wastewater, concentrated brine, sea water, high sulfur crude oil, salt spray, organic and inorganic compounds
Key Advantages
  • Short construction period
  • Superior corrosion resistance with service life exceeding 30 years
  • Low project cost
  • Easily expandable tank volume
  • Customizable colors for aesthetic appeal
  • Weather-resistant construction
  • No heavy installation equipment required
  • Simple expansion, dismantling, and relocation
Production Process
Raw Material Preparation
  • High-strength TRS (titanium-rich steel) plates specially produced for Glass-Fused-To-Steel Technology
  • Rigorous machinery preparation ensures optimal functionality
Laser Cutting
  • Precision laser cutting of steel plates
  • Automated laser cutting for bolt holes and nozzle apertures
Shot Blasting
  • Surface cleaning removes dust particles
  • Plates shot blasted to SSPC SP-10/NACE2 (Near White Metal) standard
Bending
  • Plates bent according to tank diameter specifications
  • Sampling inspection ensures proper curvature
Glass Coating
  • Panels coated with specialized glazes for different storage mediums
  • Automatic spraying coating technology per AWWAD103 standard
Firing
  • Glass coating fused to steel through firing process
  • Automatic tunnel oven firing at 800℃ for complete bonding
Inspection
  • High-standard quality control system implementation
  • Holiday test and coating thickness test on every plate
Large Glass Fused Bolted Steel Tanks Modular Design Durability For Water Management System 1
Delivery and Packaging
  • Packing: Sea-worthy standard packing or customized options
  • Port of Loading: Any port in China
  • Payment Terms: 30% advance by T/T, 70% before shipment (or L/C based on order quantity)
  • Production Period: 15-45 days depending on order size
  • Shipping: Prompt dispatch upon full payment receipt
  • Service: Professional installation guidance provided
