Customizable Bolted Steel Tanks RAL5013 Cobalt Blue Color For Chemical Industry
Product Overview
Our bolted steel storage tanks feature glass-fused-to-steel construction, providing exceptional resistance to corrosion, abrasion, and impact. This durable combination makes them ideal for harsh industrial environments.
Available in high-visibility RAL5013 cobalt blue, these tanks enable easy identification of contents, particularly beneficial for hazardous materials requiring special handling.
We offer comprehensive customization options including ladders, platforms, vents, and other accessories to tailor the tank to your specific operational requirements.
With a pH range of 1-14, our tanks accommodate both highly acidic and basic solutions. Their modular design allows cost-effective shipping and on-site assembly, significantly reducing freight expenses compared to traditional welded tanks.
Key Features
- Material: Glass-fused-to-steel construction
- Color: Standard RAL5013 cobalt blue (custom colors available)
- Corrosion Resistance: Excellent performance in harsh environments
- Freight Cost: Low due to modular design
- Holiday Test: >1100v
- Customization: Extensive options available
Technical Specifications
| Parameter |
Specification |
| Coating color |
Dark blue, dark green, white, and customized |
| Standard steel plate size |
2400mm x 1200mm (effective size) |
| Steel plates thickness |
3mm - 12mm (varies by diameter & height) |
| Coating thickness |
0.25mm - 0.45mm (two coatings internal and external) |
| Acid and alkalinity proof |
Standard coating: PH3-PH11; Special coating: PH1-PH14 |
| Adhesion |
3,450N/cm |
| Elasticity |
Same as steel sheet (~500KN/mm) |
| Hardness |
6.0 Mohs |
| Service life |
>30 years |
| Spark test |
900-1500V |
| Permeability |
Gas and liquid impermeable |
| Corrosion resistance |
Excellent against wastewater, seawater, high sulfur crude oil, and various compounds |
Applications
Industrial Water Storage: Customizable for specific needs with accessories like ladders, platforms, and vents. Easy to dismantle for relocation or modification.
Chemical/Petroleum Storage: Durable construction withstands harsh environments while keeping contents secure. Custom solutions available for specific industry requirements.
Agricultural Use: Ideal for storing water, fertilizer, and agricultural chemicals. Modular design allows adaptation to changing farm needs.
Support & Services
We provide comprehensive technical support throughout your tank's lifecycle:
- Professional installation support
- Operation and maintenance training
- On-site field services
- Repair and refurbishment services
- 24/7 emergency support
Frequently Asked Questions
Q: What is the brand name of the Bolted Steel Tank?
A: The brand name is YITIAN.
Q: What is the model number?
A: Model YT-5000DWT.
Q: Where is it manufactured?
A: Manufactured in China.
Q: What is the capacity?
A: 5000 gallons.
